Silicone Rubber
Silicone rubber polymer molecules are a chain structure formed by Si-O (silicon - oxygen) bond. Si-O bond is 443.5KJ/MOL, which is much higher than C-C bond energy (335KJ/MOL). Because of its unique molecular structure, silicone rubber has better heat resistance, electrical insulation and chemical stability than other ordinary rubber.
Typical Silicone Rubber
Typical silicone rubber,polydimethylsiloxane, is a helical molecular structure, its inter-molecular force is small, so it has good resilience, at the same time the helix methyl pointing to the outside can rotate freely, so silicone rubber has unique surface properties, such as hydrophobicity and surface anti-viscosity.
Heat resistance
Heat resistance: silicone rubber has better heat resistance than ordinary rubber and can be used permanently at 150℃without performance change. It can be used continuously for 10,000 hours at 200℃ or a short term at 350 ℃. Widely used in places requiring heat resistance, such as hot water bottle seal ring, pressure cooker ring, heat resistant handle etc.
Cold resistance
Cold resistance: the temperature range of ordinary rubber is -20~30 degree, but silicone rubber still has good elasticity when in -60~-70 degrees. Some special formulas of silicone rubber can withstand lower temperatures, such as low temperature sealing ring.
Weather resistance
Weather resistance: Ordinary rubber degrades rapidly under ozone, while silicone rubber is not affected by ozone. And for a long time in ultraviolet and other climatic conditions, its physical properties are only slightly changed, such as outdoor use of sealing materials.
Electrical properties
Electrical properties: Silicone rubber has a very high resistivity and its resistance remains stable over a wide range of temperatures and frequencies. At the same time, silicone rubber has good resistance to high voltage corona discharge and arc discharge, such as high voltage insulator, TV high voltage cap, electrical parts etc.
Electrical conductivity
Electrical conductivity: When adding conductive filler (such as carbon black), silicone rubber has electrical conductivity, such as keyboard conductive contact points, electric heating components, anti-static components, high voltage cable shielding, medical therapy conductive film.
Thermal conductivity
Thermal conductivity: When adding some thermal conductivity filler, silicone rubber will have thermal conductivity, such as heat sink, thermal sealing pad, photocopier and fax machine thermal roller etc.
Flame retardant
Flame retardant: silicone rubber is flammable, but add a small amount of flame retardant agent, it has flame retardant and self-extinguishing; And silicone rubber does not contain organic halide, when burning does not smoke or emit poison gas, suitable for strict fire places.
Air permeability
Air permeability: Silicone rubber has better air permeability than ordinary rubber and plastic. has a strong selectivity to different permeability, such as gas exchange membrane medical supplies, artificial organs etc.
In summary, the characteristics of silicone rubber:
(1)Excellent heat and cold resistance, can be used in the temperature range of -50 -- 2500C for a long time and keep its rubber elasticity.
(2)Has excellent ozone resistance, electrical insulation.
(3)Has excellent fatigue resistance, impact resistance, and can be used in sunlight for a long time.
(4)Can be filled in large quantities, can be made with rubber elastic conductive materials.
(5)Vulcanized silicone rubber can be made of sanitary products.
(6)Excellent fluidity, can be made for clothing printing material.
