Screen printing plastisol ink:mainly composed of polyvinyl chloride (PVC) and phthalates, fixing agent,stabilizer,thickener etc.in recent years,plastisol ink becomes more and more popular in the printing industry,due to its diversity(can change a variety of printing effects),Simple operation,easy to save,environmental protection and pollution-free advantages.
Introduction
Main ingredients:PVC resin (without solvent, water),plasticizer,color,other additives,solid content more than 90%.
PVC resin:fine particles,PVC molecules are chain-like structures with branched chains.
Plasticizer:the most commonly used is phthalates.
Pigment:determines the color and hiding power of the ink.
Additives:stabilizers,foaming agents,blocking agents,fillers and other effects are to change the performance of the ink.
When heated,the resin absorbs the plasticizer,undergoes a cross-linking reaction and solidifies,forming a PVC film on the surface of the fabric,and firmly binds to the fiber. The proportion of plasticizer and PVC resin should be appropriate, too little, will affect the hardness and strength. Too much, more than the saturation of resin absorption,will occur drying, sticky and other phenomena,and may even cause color shift, penetration. Generally speaking,in the inks sold by manufacturers, they have been matched in the best proportion,there is no need to adjust too much while using. Changing the type of resin,plasticizer and filler can made a various of printing effects.
Definition
Plastisol ink composition:polyvinyl chloride and phthalate, fixing agent, stabilizer, thickening agent mixed to form plastisol ink.
Plastisol ink is non-solvent-based ink,which will form a firm film on the surface after heating because the powder and the additives dissolve and plasticize into the fibers .Due to the restrictions on the use of polyvinyl chloride,it can be replaced by modified resin to meet environmental protection requirements.and the needed temperature of polyvinyl chloride plasticization is different,plastic inks can be divided into two categories: high temperature and low temperature.Plastisol ink entered the market earlier, but due to the strangeness of the operation and the limitation of production equipment,promotion speed is relatively slow,but now it has been very mature both on market promotion and production operation.
Feature
1.Paste appearance,thixotropy,while placed it looks thick,return to thin after stirring.Temperature will affect the viscosity,so viscosity is low in summer but thin in winter.
2.Because plastisol ink does not contain solvent, small volatilization at room temperature,it needs to be heated to a certain temperature to occurs cross-linking reaction,it never gets dry at room temperature,which brings great convenience to use and storage.Curing and forming PVC film to combine with fiber given itself the following characteristics:
Never block screen
No need to clean screen before taking a break
It can be printed with 350 mesh, and the network cable can reach more than 8 lines - the pattern is fine
Multi-color printing can be continuously printed enable to improve work efficiency.
Printing with perfect breathability,ultra soft hand feeling
Lessen wasting
With telescopic elasticity,adhesion fastness up to wet washing 5,dry wipe 4 or more
Both dark and light fabrics can be printed
Variety, for example three-dimensional right angle,round corner,stone effect and other special products
Application
PLASTISOL is suitable for 100% cotton, cotton/polyester blend, polyester,dark and light color cloth, denim and other fabrics,which meet the following two points can be used :1. 150°C,2. It is breathable and allow the ink penetrate.Unsuitable substrate such as: plastic, metal, glass and waterproof nylon cloth.
